SPECIFICATIONS | UNIT | |
---|---|---|
Cooling Capacity | Btu | 10,000 |
Power Supply | Phase | Single |
Volts | 115 | |
Hertz | 60 | |
Size (W x D x H) | Inches | 17.25 x 24 x 20 |
Weight | Lbs | 110 |
Current Consumption | Amps | 10 |
Circuit Breaker Size | Amps | 15 |
Power Consumption | kW | 1.1 |
Air Flow (High/Low) Evaporator | CFM | 320 / 20 |
Air Flow Condenser | CFM | 500 |
Motor Input (High/Low) Evaporator | kW | 0.093 |
Motor Input Condenser | kW | 0.18 |
Nema Plug | Type | 5-15P |
Power Cord Guage | Awg | 14AWG |
Power Cord Length | ft | 10 |
Refrigerant | Type | R410A |
oz | 15.8 | |
Operating Conditions | °F | 64~113 |
Hot Air Duct Diameter | Inches | 6 |
Maximum Hot Exhaust Duct Length | ft | 25 |
Maximum Cold Duct Length | ft | 10 |
Condensate Tank | Gal | Auto Pump Included |
