IDF-5 SCO | |
---|---|
Btu/Hr: | 1,000,000 |
Maximum Btu/hr: | 1,000,000 |
CFM: | 5,000 |
Fan Type: | Backward Inclined |
Discharge Diameter: | 18″ |
Voltage: | On-board Generator |
Fuel Type: | #1-#2 Diesel, NG or Vapor Propane |
Thermostat Control: | Mechanical – Low/High |
Max. External Static Pressure: | N/A |
Net Weight: | 8320 lbs. |
Tier 4 Compliant Generator Included: | Kubota 15kw |
Optional External Voltage: | 20 amps |
Tank Capacity: | 210 Gallon |
Secondary Containment Pans: | Yes |
Data Sheet: | IDF-5 SCO |
Dimensions: | 96″ x 185″ x 102″ |
IDF-5
Model: IDF-5
Voltages: On-board Generator
BTU/HR: 1000000 Btu/Hr
CFM: 5000
Fuel Type: #1 or #2 Diesel Fuel
Dimensions: 96" x 85" x 102"
